GS-C SERIES Fully Enclosed Side-Fed Fiber Laser Sheet Cutting Machine

GS-C SERIES Fully Enclosed Side-Fed Fiber Laser Sheet Cutting Machine Specification

Working Area
1500 x 3000 mm (upgrade options available)

Usage & Applications
Industrial Sheet Metal Cutting, Fabrication, Machinery Manufacturing, Automotive Parts, Electrical Cabinets, etc.

Power
1000W to 6000W (optional, customizable on request)

Phase
Three Phase

Technology
Fiber Laser Cutting Technology

Product Type
Fully Enclosed Side-Fed Fiber Laser Sheet Cutting Machine

Laser Type
Fiber Laser

Material
Carbon Steel, Stainless Steel, Aluminum, Brass, Copper, Alloys & More

Cutting Thickness
0.5 mm - 30 mm (depending on material and power)

Cutting Area
1500 mm x 3000 mm (customizable sizes available)

Cutting Speed
Up to 60 m/min (material and thickness dependent)

CNC Or Not
CNC

Computerized
Yes

Automatic Grade
Automatic

Cooling Mode
Water Cooling

Control Software
CypCut (or Equivalent)

Graphic Format Supported
AI, DXF, PLT, BMP, DST, DWG, LAS, DXP

Control System
CNC Control System

Voltage
380V, 50/60Hz, 3 Phase

Weight (kg)
Approx. 6500 kg (varies by model and configuration)

Dimension (L*W*H)
Approx. 4800 x 2300 x 2100 mm

Capacity
High Production Efficiency

Feature
Fully Enclosed Design; Side-feed Loading; Dust Collection; Safety Protection

Color
Standard Industrial (Customizable)

Safety
Full Enclosure with Observation Window, Security Interlocks

Working Temperature
5C - 40C

Drive System
Dual Drive Rack and Pinion

Servo Motor
Japanese Yaskawa/ Fuji (or equivalent)

Power Consumption
10 kW (varies per configuration)

Guide Rail
HIWIN (Taiwan Brand) or Equivalent

Operating Interface
Industrial Touchscreen

Environment Requirements
Humidity < 95% Non-condensing

Fume Extraction
Integrated Dust & Fume Collection System

Positioning Accuracy
0.03 mm/m

Repeat Positioning Accuracy
0.02 mm

Transmission
Import High-Precision Gear and Rack

Laser Source Brand
Raycus, IPG, or MAX (optional selection)

Table Type
Exchange Table (side-fed loading)

Lubrication
Automatic Lubrication System

Assist Gas
Oxygen, Nitrogen, Air (as per material)

Max No-Load Speed
120 m/min

Network Connectivity
Ethernet and USB

About GS-C SERIES Fully Enclosed Side-Fed Fiber Laser Sheet Cutting Machine

	GS-1510C	GS-3015C	GS-4020C
Max. material width (mm)	15001000 53.3ft	30001500 105ft	40002000 13.26.6ft
X axis travel (mm)	1020 / 3.4ft	3020 / 10ft	4020 / 13.2ft
Y axis travel (mm)	1520 / 5ft	1520 / 5ft	2000 / 6.6ft
Z axis travel (mm)	95 / 3.8in	95 / 3.8in	95 / 3.8in
X/Y positioning accuracy	0.03mm/m / 0.00118in/39.4in	0.03mm/m / 0.00118in/39.4in	0.03mm/m / 0.00118in/39.4in
X/Y repeat positioning accuracy	0.02mm / 0.00079in	0.02mm / 0.00079in	0.02mm / 0.00079in
Max. synthetic positioning speed	140m/min / 460ft/min	140m/min / 460ft/min	140m/min / 460ft/min
Max. acceleration	1.5G	1.5G	1.5G
Slit width	0.1mm-0.5mm / 0.0039in-0.0197in	0.1mm-0.5mm / 0.0039in-0.0197in	0.1mm-0.5mm / 0.0039in-0.0197in
Notch roughness	Ra3.2um-Ra25.4um / Ra0.000126-Ra0.001in	Ra3.2um-Ra25.4um / Ra0.000126-Ra0.001in	Ra3.2um-Ra25.4um / Ra0.000126-Ra0.001in
Max. cutting thickness range	Rack and pinion dual drive	Rack and pinion dual drive	Rack and pinion dual drive
Min. setting unit	0.001mm / 0.00003937in	0.001mm / 0.00003937in	0.001mm / 0.00003937in
Floor area of machine tool (mm)	40003000 1310ft	60002500 19.78.2ft	80003850 26.312.7ft
Host volume (mm)	313027502300 10.397.6ft	510024002300 16.87.97.6ft	620037602300 20.412.47.6ft
CNC system	FSCUToptinal Glorystar system	FSCUToptinal Glorystar system	FSCUToptinal Glorystar system
Monitor	27" LCD	27" LCD	27" LCD
Max. bearing capacity of workbench (tons)	0.75 / 1654lbs	1 / 2205lbs	1.8 / 3969lbs
Total installed power consumption	1500W 19.5KVA	1500W 19.5KVA	1500W 19.5KVA
Total installed power consumption	3000W 27KVA	3000W 27KVA	3000W 27KVA
Total installed power consumption	6000W 42KVA	6000W 42KVA	6000W 42KVA
Total installed power consumption	20000W 150KVA	20000W 150KVA	20000W 150KVA
Power requirements	AC380V , 50Hz ; 3P+N+PE	AC380V , 50Hz ; 3P+N+PE	AC380V , 50Hz ; 3P+N+PE
Total power protection level	IP54	IP54	IP54

Advanced Performance and Precision

Engineered with high-precision dual drive rack and pinion systems and HIWIN guide rails, the GS-C SERIES delivers reliable, repeatable accuracy-achieving 0.03 mm/m positioning and 0.02 mm repeat positioning accuracy. The imported gear and rack transmission ensures consistent, smooth movement for intricate cutting tasks.

Built-In Safety and Ease of Use

The machine features a fully enclosed design with an observation window, integrated dust and fume collection, and robust security interlocks for operator protection. Its industrial touchscreen interface, CNC control, and automatic lubrication system facilitate effortless operation and maintenance, ensuring user safety and production efficiency.

Flexible Applications and Material Handling

Ideal for a wide range of materials including carbon steel, stainless steel, aluminum, alloys, and more, the GS-C SERIES accommodates diverse industrial needs. The exchange table with side-fed loading streamlines material workflow, while customizable working areas and power options enable tailored solutions for your specific cutting requirements.

FAQ's of GS-C SERIES Fully Enclosed Side-Fed Fiber Laser Sheet Cutting Machine:

Q: How does the side-fed loading and exchange table benefit operators during sheet cutting?

A: The side-fed loading and exchange table system streamlines material handling, allowing for quick and effortless loading and unloading of sheets. This design reduces machine downtime and boosts overall production efficiency, making it easier for operators to manage large or frequent jobs.

Q: What types of materials and thicknesses can this fiber laser cutting machine process?

A: The GS-C SERIES efficiently cuts carbon steel, stainless steel, aluminum, copper, brass, and various alloys, with a typical cutting thickness range from 0.5 mm up to 30 mm-depending on the chosen laser power and material characteristics.

Q: Where can this machine be effectively utilized?

A: Designed for industrial environments, the machine serves sectors such as metal fabrication, machinery manufacturing, automotive parts production, and electrical cabinet fabrication across India and beyond, wherever precise, high-volume sheet cutting is required.

Q: What safety measures are incorporated in the GS-C SERIES cutting machine?

A: It features a fully enclosed design with observation windows, integrated dust and fume extraction, and advanced security interlocks. These features ensure operator safety by containing debris and fumes, and preventing accidental access during operation.

Q: How is the machining accuracy maintained over extended periods of use?

A: Accuracy is ensured by the high-precision dual drive rack and pinion system, premium HIWIN guide rails, and the automatic lubrication system. Together, they minimize wear and maintain consistent performance even during long production runs.

Q: What graphical file formats and software does the machine support?

A: The machine is compatible with major graphic formats including AI, DXF, PLT, BMP, DST, DWG, LAS, and DXP, and operates with CypCut or equivalent control software for seamless design input and machine operation.

Q: What are the environmental and power requirements for installation?

A: The machine requires a 380V, 3-phase electric supply, operates optimally at 5C to 40C with a humidity level below 95% (non-condensing), and consumes up to 10kW of power-depending on configuration and workload.
