NS-HG SERIES Three-Chuck Heavy-Duty Fiber Laser Tube Cutting Machine

NS-HG SERIES Three-Chuck Heavy-Duty Fiber Laser Tube Cutting Machine Specification

Working Area
Customized; typically up to 12m tube length

Phase
Three Phase

Power
1500W-12000W (as per configuration)

Usage & Applications
Cutting and processing metal tubes, industrial tubing, structural frameworks, machinery manufacturing

Technology
Heavy-duty CNC Fiber Laser Tube Cutting

Product Type
Three-Chuck Heavy-Duty Tube Cutting Machine

Laser Type
Fiber Laser

Material
Carbon Steel, Stainless Steel, Aluminum, Copper, Alloy

Cutting Thickness
Up to 35 mm (material dependent)

Cutting Area
Suitable for tubes up to 620 mm diameter

Cutting Speed
Max. 120 m/min

CNC Or Not
Yes

Computerized
Yes

Automatic Grade
Automatic

Cooling Mode
Water Cooling

Control Software
CypCut / FSCUT / TubePro

Graphic Format Supported
AI, PLT, DXF, BMP, DST, DWG, LAS, DXP

Control System
Professional CNC Control System

Voltage
380V / 50Hz (Customizable)

Weight (kg)
18000 22000 kg (model-dependent)

Dimension (L*W*H)
14500 x 2180 x 2800 mm (subject to model)

Capacity
High production capacity for heavy-duty tubes

Feature
Three-chuck design for zero tailing, high stability, and support

Color
Customizable (Standard White & Grey/Blue)

Work Environment
Indoor, dust-free, non-corrosive atmosphere

Interface Language
Multilingual support available

Repositioning Accuracy
0.02 mm

Laser Source Brand
Raycus / IPG / MAX (depending on configuration)

Operating Temperature
5C 40C

Position Accuracy
0.02 mm

Tube Shape Supported
Round, square, rectangular, oval and special profiles

Automatic Loading & Unloading
Available (optional)

Machine Frame
Welded steel structure for vibration-free operation

Chuck Type
Three pneumatic chucks with adjustable, high-precision clamping

Safety System
Protective enclosure, automatic interlocks, emergency stop

Operator Panel
Touch screen HMI

Maximum Tube Length
Up to 12 meters

Optional Accessories
Automatic nesting, waste recovery, camera monitoring, fume extractor

Drive System
Precision rack and pinion, servo motors

About NS-HG SERIES Three-Chuck Heavy-Duty Fiber Laser Tube Cutting Machine

	NS-6024HG
Max. Pipe Size	6000mm230mm / 19.7ft8.9in
Repeat Positioning Accuracy	0.03mm / 0.012in
Positioning Accuracy	0.05mm / 0.02in
Max. Positioning Speed	80m/min / 262.5ft/min
Max. Bevel Angle	45 optional
Max. Acceleration	1.0G
Max. Chuck Speed	100r/min
Pipe Weight	260Kg / 573.2lbs
Machine Weight	10T / 22046lbs
Machine Footprint	190004000mm / 62.313.2ft
Power Input	380VAC50Hz
Round Pipe Processing Range	15mm - 220mm / 0.6in - 8.7in
Square Pipe Processing Range	1515mm - 150150mm / 0.60.6in - 5.95.9in
I-Beam Processing Range	5-20# 5037mm~200102mm / 21.5in~7.84in

Exceptional Versatility and Precision

Engineered to cut a diverse array of tube shapes and sizes, the NS-HG SERIES combines adjustable pneumatic chucks with high-precision clamping. The robust three-chuck design supports zero tailing and stable operations, achieving position and repositioning accuracy of 0.02 mm. This ensures consistent results even for complex profiles.

Advanced Automation and Safety Features

Optional automatic loading and unloading systems streamline production cycles, while a protective enclosure, automatic interlocks, and emergency stop functions maximize workplace safety. The intuitive touch-screen HMI and multilingual interface enhance usability for operators in any setting.

Tailored Solutions for Heavy-Duty Industries

With customizable working areas, tube lengths up to 12 meters, and power configurations from 1500W to 12000W, this machine adapts to various industrial needs. Its rugged welded steel structure, high cutting speed, and compatibility with diverse control software (CypCut, FSCUT, TubePro) enable efficient processing of carbon steel, stainless steel, aluminum, copper, and alloys.

FAQ's of NS-HG SERIES Three-Chuck Heavy-Duty Fiber Laser Tube Cutting Machine:

Q: How does the three-chuck pneumatic clamping system enhance tube cutting precision and stability?

A: The three-chuck pneumatic clamping system provides adjustable, high-precision clamping at multiple points along the tube, minimizing vibrations and movement during cutting. This multi-chuck design ensures zero tailing and maintains excellent stability, which is crucial for achieving accurate cuts, especially on long and heavy-duty tubes.

Q: What types of tubes and profiles can be processed with the NS-HG SERIES machine?

A: This machine supports a wide range of tube shapes including round, square, rectangular, oval, and special custom profiles. With its advanced clamping and positioning system, it efficiently accommodates tubes up to 12 meters in length and diameters up to 620 mm, allowing flexibility for various industrial applications.

Q: When should the automatic loading and unloading feature be considered for integration?

A: The automatic loading and unloading function is recommended for high-volume production environments where efficiency and cycle times are critical. Integrating this optional feature reduces manual handling, accelerates operations, and improves overall productivity by automating both the feed and discharge of tubes.

Q: Where is the NS-HG SERIES Fiber Laser Tube Cutting Machine ideally used?

A: This machine is best suited for indoor, dust-free, and non-corrosive environments, such as industrial fabrication shops and manufacturing plants. Its sturdy, vibration-free construction makes it ideal for sectors demanding high production capacity-structural framework processing, machinery manufacturing, and metal tubing applications.

Q: What is the process for cutting tubes with various profiles and materials using this machine?

A: Operators input cutting parameters using the touch-screen HMI, supported by control software (CypCut, FSCUT, or TubePro). The machine's CNC system manages precise positioning and movement of tubes, while the fiber laser cuts through carbon steel, stainless steel, aluminum, copper, or alloys up to 35 mm thick, delivering high-speed, accurate results.

Q: How does the machine enhance user productivity and operational safety?

A: The NS-HG SERIES is equipped with protective enclosures, emergency stop features, and interlocks for operator safety. Efficiency is boosted with optional automation, intuitive control panels, camera monitoring, and waste recovery options. Multilingual support ensures seamless operation for users in diverse regions.

Q: What are the key benefits of using the NS-HG SERIES Three-Chuck Fiber Laser Tube Cutting Machine?

A: Key advantages include precise and stable cutting with minimal tailing, support for a variety of tube shapes and materials, efficient automated functions, and a robust welded steel frame for vibration reduction. The machine ensures rapid production speeds (up to 120 m/min), superior accuracy, and adaptability to heavy-duty industrial requirements.
