GB-A SERIES Fully Automatic High-Speed Bending Center

GB-A SERIES Fully Automatic High-Speed Bending Center Specification

Bend Radius
As per Tooling/Min. 0.5 mm

Machine Type
Fully Automatic High-Speed Sheet Bending Machine

Automation
Fully Automatic

Capacity
Up to 3 mm Thickness (Mild Steel)

Bending Strength
150 kN

Bending Speed
0.21.5 s/bend

Power
11 kW

Voltage
380V / 415V

Bending Angle
0135

Color
Gray

Place of Origin
China

Output
High Output Efficiency

Raw Material
Sheet Metal

Production Capacity
300-400 pcs/hour

Condition
NEW

Dimension (L*W*H)
4200 2100 2550 mm

Motor Speed
1440 rpm

Weight
7500 kg

Usage
Industrial Sheet Metal Bending

Phase
Three Phase

Product Type
Bending Center

Positioning Accuracy
0.05 mm

Interface
Ethernet/USB

Cooling System
Industrial Cooling Fan

Lubrication
Automatic Centralized

Control System
CNC Touch Panel

Tool Change Time
16 seconds (automatic tool changer)

Safety Features
Automatic Safety Guard, Emergency Stop Button

Workpiece Size Range
Min. 150 mm 150 mm to Max. 1200 mm 2500 mm

Noise Level
80 dB

Material Compatibility
Mild Steel, Stainless Steel, Aluminum

Clamping Type
Hydraulic Automatic

About GB-A SERIES Fully Automatic High-Speed Bending Center

	GB-1200A	GB-1500A	GB-2000A	GB-2500A
Bending Length	1200mm / 4ft	1500mm / 5ft	2000mm / 7ft	2500mm / 8ft
	4 sides 170mm / 6.69in	4 sides 170mm / 6.7in	4 sides 170mm / 6.7in	4 sides 170mm / 6.7in
Bending Height	4 sides 170mm / 6.69in	2 sides 170mm(6.7in) / 2 sides 350mm(13.8in	2 sides 170mm(6.7in) / 2 sides 350mm(13.8in	2 sides 170mm(6.7in) / 2 sides 350mm(13.8in
	4 sides 170mm / 6.69in	4 sides 350mm / 13.8in	4 sides 350mm / 13.8in	4 sides 350mm / 13.8in
Max. Bending Size	12001200mm 44ft	15001500mm 55ft	20001500mm 75ft	25001500mm 85ft
Max. Bending Thickness	2mm / 0.08in	3mm / 0.12in	3mm / 0.12in	3mm / 0.12in
Max. thickness of iron plate	1.5mm / 0.06in	2mm / 0.08in	2mm / 0.08in	2mm / 0.08in
Max. thickness of stainless steel	0.8mm / 0.03in	1.5mm / 0.06in	1.5mm / 0.06in	1.5mm / 0.06in
Maximum Bending Speed	0.2s/per bend	0.2s/per bend	0.2s/per bend	0.2s/per bend
Dimensions 4 sides 170	159029502666mm 5109ft	189033002666mm 6119ft	239039002800mm 8139ft	289045002800mm 9159ft
Dimensions 2-4 sides	/	189035362946mm 61210ft	236041102936mm 81310ft	290044602936mm 101510ft
Dimensions 350Vacuum Cup	/	189041272946mm 61410ft	236045002946mm 81510ft	288049503090mm 91610ft
Weight (4 sides 170)	8000kg 17637lbs	10000kg 22046.3lbs	14000kg 30864.8lbs	17000kg 37478.6lbs
Weight (2-4 sides 350 Vacuum Cup)	/	17000kg 37478.6lbs	14000kg 30864.8lbs	14000kg 30864.8lbs

High-Speed Bending, Precision Assured

Achieve rapid, reliable results with the GB-A SERIES Bending Center, featuring industry-leading tool change times and accurate bending every cycle. Its CNC touch panel streamlines operations, while an advanced hydraulic system ensures stable clamping and high bending strength. Exceptional efficiency and tight tolerances make it ideal for demanding industrial sheet metal applications.

Designed for Versatility & Safety

The machine accommodates a wide range of workpiece sizes and is compatible with various materials, including mild steel, stainless steel, and aluminum. Comprehensive safety features such as an automatic guard and emergency stop button offer operators peace of mind, while centralized lubrication and cooling maintain machine longevity and performance.

FAQ's of GB-A SERIES Fully Automatic High-Speed Bending Center:

Q: How does the automatic tool changer benefit the production process?

A: The automatic tool changer reduces tool change times to just 16 seconds, significantly minimizing downtime and optimizing workflow during batch production. This rapid changeover increases overall productivity and enables efficient handling of multiple bending operations.

Q: What types of sheet metal can the GB-A SERIES bend?

A: The GB-A SERIES is compatible with mild steel, stainless steel, and aluminum sheets, making it suitable for diverse industrial applications requiring different materials.

Q: When should I use the automatic safety guard and emergency stop features?

A: These features are designed to activate in hazardous situations or during unforeseen incidents. Operators should always ensure the safety guard is engaged during operations, and activate the emergency stop button immediately if any unsafe condition arises.

Q: Where is the GB-A SERIES most effectively used?

A: This machine is ideal for use in industrial manufacturing facilities, particularly in sectors that demand high-speed, high-accuracy sheet metal bending such as automotive, HVAC, electrical enclosures, and appliance fabrication.

Q: What is the process to operate the machine using the CNC touch panel?

A: Operators input bending parameters, select tooling, and monitor machine status directly from the CNC touch panel. The interface provides an intuitive workflow for setup, operation, and real-time adjustment, streamlining the complete bending process.

Q: How does the cooling and lubrication system enhance machine performance?

A: The industrial cooling fan prevents overheating during continuous operation, maintaining consistent output. Automated centralized lubrication reduces wear on moving parts, extending the machine's longevity and ensuring smooth, trouble-free operation.
