AHW-SERIES Air-Cooled Handheld Laser Welding Machine

AHW-SERIES Air-Cooled Handheld Laser Welding Machine Specification

Usage
Metal Welding, Stainless Steel, Aluminum, Carbon Steel, Galvanized Sheet etc.

Weight
Approx. 38-45 kg (varies by model)

Efficiency
>85%

Pulse Frequency
Up to 5000Hz

Voltage
220V 10% / 380V (dependent on configuration)

Condition
New

Cooling Method
Built-in Air Cooling

Rod Diameter
No electrode rod (laser welding, not arc)

Welding Area
0.5-5 mm thickness (varies by material & power)

Frequency
50/60 Hz

Input Current
20A (for 2000W)

Arc Current
Adjustable and dependent on machine power

Motor Type
Brushless DC Motor (for wire feeder, if equipped)

Function
Continuous & Pulse Laser Welding

Power
1000W / 1500W / 2000W (configurable)

Insulation Grade
F

Dimension (L*W*H)
625 x 295 x 545 mm (varies slightly by model)

Type
Air-Cooled Handheld Laser Welding Machine

Output Current
10A - 200A (approx., depends on power)

Material
Stainless Steel housing & laser components

Welding Speed
Up to 4X faster than conventional welding

Relative Humidity
70% (non-condensing)

Operation Mode
Handheld

Application
Automotive, Construction, Furniture, Industrial manufacturing

Display Interface
Touch screen digital control panel

Supported Materials
Stainless steel, Carbon steel, Aluminum, Galvanized steel, Iron, Other alloys

Accessories Included
Wire feeder system, Protective lenses, Welding nozzles, User manual

Cable Length
10 meters (standard, customizable)

Laser Wavelength
1080 nm

Laser Type
Fiber Laser

Gas Supply
Argon/Nitrogen recommended

Safety Features
Emergency stop, Interlock protection, Laser eye protection

Ambient Temperature
5C - 40C

About AHW-SERIES Air-Cooled Handheld Laser Welding Machine

	AHW40	AHW30
Welding thickness	Stainless Steel 0.5-4mm 0.02-0.16in Carbon Steel 0.5-4mm 0.02-0.16in Galvanized Sheet 0.5-3mm 0.02-0.12in Aluminum 3mm 0.12in Brass 3mm 0.12in	Stainless Steel 0.5-3mm 0.02-0.12in Carbon Steel 0.5-3mm 0.02-0.12in Galvanized Sheet 0.5-2mm 0.02-0.08in Aluminum 2mm 0.08in Brass 2mm 0.08in
Spot adjustable range	0-5mm / 0-0.20in	0-5mm / 0-0.20in
Cooling method	Air cooling	Air Cooling
Protective gas	Noble gas	Noble gas
Weight	26kg / 57.32lbs	26kg / 57.32lbs
Dimensions	250579479mm / 122ft	250579479mm / 122ft

Efficient and Adaptable Welding for Modern Industry

Benefit from rapid, high-precision welding with the AHW-SERIES. Its fiber laser technology, with variable power configurations, accommodates a diverse range of materials and thicknesses. The air-cooled design ensures stable operation within ambient temperatures of 5C to 40C, making it suitable for workshops and field sites. Digital control and an ergonomic handheld mode promote ease-of-use while maintaining quality and consistency.

Broad Material Compatibility and Application

Tackle projects in automotive, construction, furniture, and general industrial manufacturing thanks to support for stainless steel, carbon steel, aluminum, galvanized steel, iron, and alloys. Whether fabricating new equipment or repairing existing structures, the AHW-SERIES adapts seamlessly to a variety of metalworking requirements. Its adjustable welding parameters accommodate both delicate assemblies and robust, thick-metal joints.

Comprehensive Safety and User Support

The machine prioritizes operator safety with features like emergency stop, interlock protection, and laser eye protection. Combined with a digital touch screen interface, built-in wire feeder, protective lenses, and a comprehensive user manual, the system is accessible to experienced welders and newcomers alike. Adjustable output and process controls let users optimize performance with confidence.

FAQs of AHW-SERIES Air-Cooled Handheld Laser Welding Machine:

Q: How does the AHW-SERIES Air-Cooled Handheld Laser Welding Machine improve welding speed compared to traditional methods?

A: The AHW-SERIES utilizes advanced fiber laser technology to deliver welding speeds up to four times faster than conventional arc or MIG/TIG welding. This efficiency results from rapid, precise energy transfer and reduced post-weld finishing, making it an excellent choice for high-throughput production and time-sensitive repairs.

Q: What types of materials can be welded with the AHW-SERIES machine?

A: This welding machine supports a broad range of materials including stainless steel, carbon steel, aluminum, galvanized steel, iron, and other alloys. Its adjustable power configurations and digital controls cater to varying thicknesses and project requirements.

Q: When is it recommended to use Argon or Nitrogen as the shielding gas?

A: Argon or Nitrogen gases are recommended as shielding gases during operation to prevent oxidation and ensure high-quality weld joints. The selection may depend on the material being welded and the desired appearance or finish of the weld.

Q: Where can the AHW-SERIES be used effectively?

A: This machine is suitable for a wide range of settings including automotive garages, construction sites, furniture workshops, and industrial manufacturing plants. Its 10-meter cable and air-cooled, portable design make it especially valuable where mobility and flexibility are needed.

Q: What safety features are included with the AHW-SERIES welding machine?

A: Operator safety is ensured through emergency stop functions, interlock protection, and integrated laser eye protection. These safety mechanisms help prevent accidental exposure and equipment misuse during operation.

Q: How does the digital touch screen interface enhance the user experience?

A: The touch screen digital control panel simplifies parameter adjustments, allows for precise control over the welding process, and displays workflow statistics, making it easier for operators to monitor and improve their performance.

Q: What accessories come standard with the AHW-SERIES laser welding system?

A: The machine is supplied with essential accessories including a wire feeder system, protective lenses, various welding nozzles, and a detailed user manual. These components facilitate immediate setup and safe operation out of the box.
